Wall Partitions

Ptech provides a very wide range of clean room compatible doors . These are made for air ingression in the room. The door has complete mechanically interlocked vertical edges which adds to the strength and rigidity, thus making  it appropriate for light and heavy use.

Clean room doors are available  for a flush and easy installation on existing walls.

•  A large variety of swing out pharmaceutical doors
• Fully flush surfaces with wall system
• Door hardware by world market leading manufacturers
• Manual, semiautomatic and fully automatic sliding doors
• Heavy-duty structure for high durability
• Custom dimensions available

The flush doors are thick made of 0.8 mm thick PU powder coated GPSP sheet with honeycomb kraft paper , PUF as infill, 1.2 mm thick GPSP powder coated door frames and with provisions for double glazing glass , hardwares which are like push plate, door closure, SS D handle, SS ball bearing butt hinges, concealed tower bolt for the double door among others.

Different Types of Doors

• Scientific Doors
• Emergency Doors
• Fire Rated Doors
• Roll up Doors
• Sliding Doors



Infill

• Honey Comb Kraft
• Rock Wool
• PUF (Polyurethane Foam)

CLEANROOM DOORS – SPECIFICATIONS:
Features:
Flush Metal Doors with Single leaf ,Double Leaf ,Unequal double leaf
Epoxy powder coated with a thickness of 60-80 microns.
Material of Construction: Galvanized Iron / Stainless Steel.
Frame Thickness: As per required sizes.
Framework sheet thickness: 1.2 mm thick.
Surface Finish: Powder Coated / Stainless Steel.
Insulation: Honey comb Kraft / PUF(Polyurethane Foam )/ Mineral Wool.
Our Flush Metal Doors are tailored to the requirements of the client . Various color shades are available as required.
Cleanroom doors are fixed with reputed makes Hardware.

• Door Closer.
• SS Ball bearing Hinges.
• Door Drop seal.
• SS Door Handles.
• Double glaze view Glass.
• Door Lock.
• Kick Plates & Push Plates.

Optional Accessories:

• Tower Bolt.
• Panic bar for Emergency Doors.
• Access control system.
• Interlocking system with central control system.
